Lifepo4 12V 200Ah Solar Energy Storage Lithium Ion Batteries
1. Lifepo4 12V 200Ah Solar Energy Storage Lithium Ion Batteries that can be mounted in any position, resists shocks and vibration. Long lasting high performance in high and low temperatures.
2. Efficient Power: Our LiFePO4 battery’s flat discharge curve holds above 12V for up to 95% of its capacity usage providing astronomical boosts in run-time compared to only 50% in Lead Acid.
3. Impeccably Lightweight: Our LiFePO4 battery is only a 1/3 of the weight of Lead Acid which makes it the disputable choice for RVs, Marine and Off-Grid Applications when towing or mobility is in the consideration.
4. Original factory directly sell with lowest price;
5. Good quality
Send Inquiry
Product Introduction
Shenzhen Benwei Lighting Technology Co., Ltd. is one of the best manufacturers and suppliers of lifepo4 12v 200ah solar energy storage lithium ion batteries in China. Welcome to buy durable products for sale here and get pricelist from our factory. All customized products are with high quality and competitive price.
Lifepo4 12V 200Ah Solar Energy Storage Lithium Ion Batteries
Product Features:
1. Lifepo4 12V 200Ah Solar Energy Storage Lithium Ion Batteries that can be mounted in any position, resists shocks and vibration. Long lasting high performance in high and low temperatures.
2. Efficient Power: Our LiFePO4 battery’s flat discharge curve holds above 12V for up to 95% of its capacity usage providing astronomical boosts in run-time compared to only 50% in Lead Acid.
3. Impeccably Lightweight: Our LiFePO4 battery is only a 1/3 of the weight of Lead Acid which makes it the disputable choice for RVs, Marine and Off-Grid Applications when towing or mobility is in the consideration.
4. Original factory directly sell with lowest price;
5. Good quality
6. Low MOQ, sample order is welcomed;
| Nominal voltage | 12.8V |
| Nominal capacity | 200ah（OEM） |
| Battery type | Top grade A 3.2V 50ah LifePO4 pouch Lithium iron phosphate battery cell |
| Model | DL-12200/4S4P |
| Battery configation | 4S4P |
| Internal resistance | ≤420mΩ |
| End of charge voltage | 14.6V |
| End of charge current | 200mA |
| End of discharge voltage | 9.2V |
| Charge method | CC/CV(constant current/constant voltage) |
| Max continuous charge current | 100-200A ( suggetsion) |
| Continuous discharge current | 100A or 200A |
| Max pulse discharge current | 200a-300a/10S |
| Net weight | 22KG gross weight |
| Case material | ABS case or metal case or stainless steel case |
| Case dimension | 200ah ：360*270*190mm （ all dimension can be customized ） |
| Warranty | 2 years. 3 years for seller |
| Built-in BMS | 100A Monitoring of cell and PCB temperature, current, voltage, cell balancing, etc |
| Terminal Type | M8 OR Anderson |
| Lifecycle | Deep cycle life 2000 times, 80%dod,5000 times , 65% dod, 8000 times, 40% dod |
| Charge temperature | 0~45℃ |
| Discharge temperature | -20~60℃ |
| Storage temperature | -10~45℃ |
| Certificate | CE, RoHS ,MSDS and UN38.3 certification |
| Parallel assembly | up to 10 items (12V-1000Ah or more ) |
| Enclosure Protection | IP56 or customized IP67 available |
| Sticker | OEM sticker welcome, you can sent desgin for customization |
lifepo4 battery advantage:
1.Long Cycle Life, 2000+ Cycles.
2.High Capacity: 12.8V 200Ah 2560Wh. Output voltage: 14.6V-9V (Nominal: 12.8V). Output Current: 100A continuous.
12V lithium ion battery pack output voltage is output directly from 4S Li-Ion battery by through the PCM, so the output voltage is not constant. But more than 90% of the time, the output voltage is about from 12V to 13V in one of discharge cycle.
3.Appearance shape, size of the product is similar to the specifications of traditional lead-acid batteries, so you can be installed directly instead of the customary lead-acid battery.【Please note: this battery can't be used as a Jump Starter Battery!!!】
4.Compared with lead-acid battery, the LiFePo battery has higher capacity, is lighter and much better. Lithium battery have excellent characteristics, for example: large capacity, small volume, light weight, etc. It will bring a very convenient experience to users. Note: the package not included the charger, please purchase it separately.
5.Package content: 1pcs 12V 200ah LiFePO4 Battery Pack 【No battery charger. Please use the 14.6V LiFePO4 Battery Charger to charge, the package not included the charger, you need to purchase it separately!!!】
Main Applications For 12v lithium ion battery pack:
Large-scale electric vehicles: electric bus, electric car, E-Tour Car.
rechargeable aa lithium batteries Light, electric car: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair.
E-tool: electric drill, electric saw, lawn mower and so on.
Remote control cars, electric boat, aircraft, toys.
Solar and wind power generation energy storage devices,solar systems,Telecom base Station.
Small medical equipment and portable equipment.
RV,Camping car and yacht.8.Solar enegery lights,bicycle lights,LED lights,bright flashlight.
Package for rechargeable aa lithium batteries:
