Smd Led 2835 1w Full Spectrum

Product Features:
Power Range: 0.2W, 0.5W, 1W, 1.5W, 2W Power Dissipation Available.
Forward Voltage: 3V, 6V, 9V, 18V, 36V.
Forward Current: 30mA, 60mA, 100mA, 150mA, 350mA.
Color Rendering Index: Ra80, Ra90, Ra95, Ra98, 99Ra.
High Light Efficacy: 220LM/W available.

Send Inquiry

smd led 2835 1w full spectrum

led module smd 2835

Product Features of smd led 2835 1w full spectrum:

Power Range: 0.2W, 0.5W, 1W, 1.5W, 2W Power Dissipation Available.

Forward Voltage: 3V, 6V, 9V, 18V, 36V.

Forward Current: 30mA, 60mA, 100mA, 150mA, 350mA.

Color Rendering Index: Ra80, Ra90, Ra95, Ra98, 99Ra.

High Light Efficacy: 220LM/W available.

CCT Range: 1600-1800K, 1800-2000K, 2000-2200K, 2200-2400K, 3000-10000K.

Light Color: Red, Green, Blue, Yellow, UV, IR...

Full Spectrum 380-850nm.

Specifications:

2835 LED SERIES SPECIFICATION
Product Name	Light Color	CCT/Wavelength	Voltage	Current	Lumen	Remarks
0.2W 2835 LED	Gold Yellow	1800-2000K	2.8-3.4V	60mA	24-30LM	CRI80,90
0.2W 2835 LED	White	3000-6500K	2.8-3.4V	60mA	24-34LM	CRI80,90,96+
0.5W 2835 LED	White	3000-6500K	2.8-3.4V	150mA	55-75LM	CRI80,90,96+
1W 2835 LED	White	3000-6500K	6/9/18/36V	150/100/50/30mA	90-150LM	High Voltage Series
2835 UV LED	UV	365-410nm	3/6/9V	60/150/175/100mA	/	0.2W, 0.5W, 1W
2835 Blue LED	Blue	440-470nm	3/6/9V	60/150/175/100mA	4-20LM	0.2W, 0.5W, 1W
2835 Green LED	Green	520-530nm	3/6/9V	60/150/175/100mA	18-80LM	0.2W, 0.5W, 1W
2835 Amber LED	Yellow/Amber	590-610nm	2/4/6V	60/150/175/100mA	6-20LM	0.2W, 0.5W, 1W
2835 Red LED	Red	620-630nm	2/4/6V	60/150/175/100mA	8-30LM	0.2W, 0.5W, 1W
2835 Far Red	Far Red	660-665nm	2/4/6V	60/150/175/100mA	3-12LM	0.2W, 0.5W, 1W
2835 IR LED	IR	730-750nm	2/4/6V	60/150/175/100mA	/	0.2W, 0.5W, 1W
2835 IR LED	IR	850nm	2/4/6V	60/150/175/100mA	/	0.2W, 0.5W, 1W
2835 PC Blue	Phosphor Blue	450-470nm	3/6/9V	60/150/175/100mA	6-30LM	0.2W,0.5W,1W Customized WD,WP
2835 PC Green	Phosphor Green	510-530nm	3/6/9V	60/150/175/100mA	18-120LM
2835 PC Color	Phosphor Amber/Red	600-630nm	3/6/9V	60/150/175/100mA	10-60LM
