Most Efficient Led Chip
Forward Current 350mA 150mA 100mA
Color Rendering Index: RA80, RA90, RA93, RA95+, RA98
High Light Efficacy: 220LM/W+
Send Inquiry
Product Introduction
Shenzhen Benwei Lighting Technology Co., Ltd. is one of the best manufacturers and suppliers of most efficient led chip in China. Welcome to buy durable products for sale here and get pricelist from our factory. All customized products are with high quality and competitive price.
most efficient led chip
Features:
Power: 1W-2W 3/6/9/12/18V 100-135lm
• Viewing angle at 50 % IV: 120°
• Color: 2700K - 8000K (white)
• CRI: min. 80 (typ. 82 )
• Luminous flux: typ. 112lm 3000K
• Luminous efficacy: typ. 118lm/W 3000K
• Lumen maintenance: test results according to IESNA LM-80 available
Specifications of most efficient led chip:
| 3030 SMD LED SERIES SPECIFICATION | ||||||
| Product Name | Light Color | CCT/Wavelength | Voltage | Current | Lumen | Remark |
| 3030 LED | Gold Yellow | 1800-2000K | 3/6/9V | 350/175/100mA | 120-220LM | CRI80,90 |
| 3030 LED | White | 3000-10000K | 3/6/9V | 350/175/100mA | 120-220LM | CRI80,90,96+ |
| 3030 UV LED | UV | 365-370nm | 3/6/9V | 350/175/100mA | / | Epileds Chip |
| 3030 UV LED | UV | 390-400nm | 3/6/9V | 350/175/100mA | / | Epileds Chip |
| 3030 BLUE LED | Blue | 440-470nm | 3/6/9V | 350/175/100mA | 12-20LM | Epileds Chip |
| 3030 Green LED | Green | 520-530nm | 3/6/9V | 350/175/100mA | 70-100LM | Epileds Chip |
| 3030 Amber LED | Yellow/Amber | 590-610nm | 2/4/6V | 350/175/100mA | 20-25LM | Epileds Chip |
| 3030 Red LED | Red | 620-630nm | 2/4/6V | 350/175/100mA | 30-35LM | Epileds Chip |
| 3030 Far Red | Far Red | 660-665nm | 2/4/6V | 350/175/100mA | 12-15LM | Epileds Chip |
| 3030 IR LED | IR | 730-750nm | 2/4/6V | 350/175/100mA | / | Epileds Chip |
| 3030 IR LED | IR | 850nm | 2/4/6V | 350/175/100mA | / | Epileds Chip |
| 3030 PC Blue | Phosphor Blue | 450-470nm | 3/6/9V | 350/175/100mA | 15-30LM | Customized WD, WP |
| 3030 PC Green | Phosphor Green | 510-530nm | 3/6/9V | 350/175/100mA | 140-200LM | Customized WD, WP |
| 3030 PC Color | Phosphor Amber/Red | 600-630nm | 3/6/9V | 350/175/100mA | 50-60LM | Customized WD, WP |
More pictures:
FAQ:
1.How do I place an order?
You can place an order by email or online.
2.How can I pay you?
T/T, Paypal, Western Union are our most commonly used methods.
3.What is the ordering procedure?
First we discuss order details, product details. Then we will send you a P / I for your confirmation.You will be requested to prepay full payment or deposit Before we produce the goods, After receiving the deposit, we start processing the order. If we don’t have stock, we usually need 7-15 days. Before the production is completed, We will contact you for shipping details and balance payment. After the payment is completed, we will start shipping for you.
4.How can I get the price?
We usually quote within 24 hours after receiving your inquiry (except weekends and holidays). If you are very anxious to get the price, please email us or contact us by other means so that we can provide you with a quotation.
5.What is your delivery time?
It depends on the number of orders and the season in which you placed the order.
Usually we can ship within 7-15 days, if the quantity is relatively large, we need to negotiate the delivery time
