48V DC No Voltage Drop Poultry LED Tube Light
1.With the IP67 Waterproof grade, the T12 Poultry lighting can hold on the high-pressure water jet, Amnonia Gas and other cleaning chemical resistance.
2.From the beginning to the end all lights are almost in same light intensity.
3.Our Poultry Waterproof LED Lamp is available for quick installation with plug-and-play connectors
4.with 2700-6000K CCT switchable , it can simulate sunrise and sunset automatically
5.With 0-100% dimming , it can smoothly adjust the brightness of the led lamp .
Send Inquiry
Product Introduction
Shenzhen Benwei Lighting Technology Co., Ltd. is one of the best manufacturers and suppliers of 48v dc no voltage drop poultry led tube light in China. Welcome to buy durable products for sale here and get pricelist from our factory. All customized products are with high quality and competitive price.
Features
·
1. Safety: 48V DC has significant advantages
Low risk of electric shock:
The chicken house environment is humid (needs regular high-pressure water gun washing), 48V DC belongs to safety extra low voltage (SELV), and there is no risk of electric shock even if directly contacted.
However, 220V AC has a high risk of leakage in a humid environment and requires additional protection (such as IP66 level), which increases cost and complexity.
Simplified equipment protection:
48V DC lamps do not require complex grounding protection, reducing safety hazards caused by line faults18.
2. Energy efficiency and system design: each has its pros and cons
48V DC system:
Low conversion loss: Directly drive LEDs to avoid energy consumption of multiple AC-DC conversions (traditional AC lamps require rectification and voltage reduction, with an efficiency loss of 5-20%).
Precise dimming: DC dimming has no flicker, avoiding poultry stress response. Experiments have shown that LED dimming can accurately match the lighting requirements of laying hens at different growth stages and improve egg production stability.
220V AC system:
Suitable for high-power scenarios: If the power of a single lamp is >1500W (such as centralized lighting in a large chicken house), 220V AC can reduce line current and transmission loss.
Advantages of high-voltage LEDs: New high-voltage LEDs (such as 50V single chips) can reduce AC-DC voltage difference and improve conversion efficiency, but the cost is higher
parameters
| products |
 |
|
|
|
| Length | 60CM | 90CM | 120CM | 150CM |
| Power | 9/10 /12/14/16/18/20/22/23/25/28/30W | |||
| Input Voltage | 220V AC, 110V AC , 48V DC | |||
| Material | Aluminium + pC cover | |||
| Luminous flux | 140-160lm/W | |||
| CCT | 3000K/4000K/5000K/6000K ( 3000-6000k selectable optional) | |||
| IP Grade | IP67 | |||
| Flicker | Flicker free (Flicker index <0.001) | |||
| CRI | CRI：90-92 | |||
| Beam Angle | 180° | |||
| Lifespan | 50000Hours | |||
| PF | ＞0.9 | |||
| Warranty | 5years | |||
Installation and maintenance: 48V DC is more convenient
Simplified wiring:
48V DC lamps often adopt a series design, with waterproof connectors directly connected between lamps, without independent wiring, reducing the construction volume (such as the factory pre-installed in a string of light tubes)28.
220V AC requires branch wiring, which increases cable costs and electrician investment.
Low maintenance cost:
The 48V DC system has a low failure rate, and the dimming power supply (such as the 2000W power supply of the light) supports overheating self-recovery and has a lifespan of up to 3 years1;
If the driver of the 220V AC lamp is damaged, the replacement cost is high (such as the Philips dimming module requires special accessories)
Poultry production performance: Both are applicable, but the dimming function is the key
Spectrum and intensity adjustment:
Whether 48V DC or 220V AC, LED lamps can achieve 3000K yellow light (for laying hens) or 6500K white light (for broilers), and support 0-100% dimming58.
The intelligent system can simulate sunrise and sunset, reduce poultry stress, and increase egg production by 5-10%
No flicker requirement:
DC power supply is naturally flicker-free, while AC lamps require high-quality drivers to avoid flicker (poor quality products can easily lead to pecking in chickens
product key technologies
01.
T8 waterproof poultry lamps are a great option for a number of reasons.
They are ideal for use in damp areas like kitchens and bathrooms because to their remarkable degree of waterproofing, and they are available in a variety of sizes and designs to complement any style.
02. Real pictures
03.
Poultry light production is a crucial technology in modern farming systems.
It offers several benefits, including promoting growth and development,paving the way for a more sustainable and efficient industry,regulating reproductive cycles, improving animal welfare, and protecting the environment.
04.
High quality PC cover,safe plastic body.
PVC flame retardant waterproof wire,IP68 protection.
Tubes come in both clear and frosted varieties, while white is available in neutral, cool, and mild temperature options.
05.
· The world's leading DualMos rear edge cutting phase dimming technology, 0-100% no stroboscopic
· 0-100% brightness dimming to simulate sunrise and sunset to improve animal welfare
· Two road output, each road can be separately adjustable, have a separate schedule,
· can simulate the sunrise and sunset Support the slave control mode 0-10V control signal, the threshold can be matched
· Support for manual dimming, and the manual dimming is still soft and smooth
· Supports dimming based on light illumination value
· Power off memory function, continue to run according to the original schedule after the power off restart
· 7-inch 600x 1024 IPS capacitive touch LCD screen
· Hanging wall installation
· Waterproof grade IP 66
· The warranty is three years
06.
This poultry LED light digital dimmer supports custom settings for turning on and off the lights, and can set the brightness of the lights to help you reduce your burden. It is very efficient and accurate.
Benwei poultry LED light production can regulate the reproductive cycles of birds. By controlling the light exposure, farmers can time when their birds lay eggs, making it easier to manage egg production and optimize their resource utilization. This can lead to increased productivity and overall profitability for the farm.
Applications
The 48V DC solution is more in line with the needs of modern chicken farms, especially with its advantages of zero risk, precise dimming, and long-term power saving, it has become the mainstream. For example, BENWEI Lighting's DC48V system (lamp tube + smart dimming box) has achieved "safe voltage + programmed lighting", with significant comprehensive benefits.
If the chicken house has AC power distribution and does not require fine dimming, high-voltage LED 220V AC lamps can be used as a transitional solution, but strict moisture-proof and grounding protection must be done.
Poultry light production has been found to boost animal welfare in addition to growth and development. The consistent and cosy environment that poultry houses' specialised lighting systems offer to the birds lowers stress levels and improves their general well-being
Our Company
Shenzhen Benwei Lighting Technology Co., Ltd is a professional manufacturer in producing LED lighting products, integrates design, development, production and sales of high-tech products as a whole. The fcatory was founded in 2008, is located in shenzhen. Now has over 300 employees, the annual sale of us is about USD 6 million and has become a leader in the industry. The company has a strong research and development team and high-end precision production equipment.
