Name: China Hybrid Solar Inverter 5kw Suppliers, Manufacturers, Factory - Best Price - Benwei
Brand: Benwei
SKU: 188673038

Shenzhen Benwei Lighting Technology Co., Ltd. is one of the best manufacturers and suppliers of hybrid solar inverter 5kw in China. Welcome to buy durable products for sale here and get pricelist from our factory. All customized products are with high quality and competitive price.

hybrid solar inverter 5kw

Feature:

# Parallel Function up to maximum 9 units : Enlarge More Loads .

# Communication option: External WIFI, Supervise at Any Time.

# Slim Body, Convenient Installation And Transportation, Cheaper Freight by Air,Sea and Land.

# PF1.0, High Efficiency, Lower consumption : Energy Conservation/Environmental Protection/Electricity Saving/Cost Saving.

# Support working without battery:Reduce solar system cost and save money.

# High precision of output voltage,±5%，take care of your appliances.

Product Parameters:

BWGA hybrid solar inverter 5kw
Model		BWGA3024ML	BWGA3024MH	BWGA5048MH
Input	Phase	L+N+PE
	Nominal Voltage	208/220/230/240VAC
	Voltage Range	154-264VAC±3V（Normal Mode) 185-264VAC±3V（UPS Mode）
	Frequency Range	50Hz/60Hz(Adaptive)
Output	Rated Power	3000W	3000W	5000W
	Output Voltage(AC)	208/220/230/240VAC±5%
	Output Frequency	50/60Hz±0.1%
	Waveform	Pure sine wave
	Transfer Time( Optional)	10ms for computer , 20ms for home appliances
	Peak power	6000VA	6000VA	10000VA
	Overload	Battery Mode： 1min@102%~110% Load 10s@110%~130% Load 3s@130%~150% Load 200ms@>150% Load
	Peak efficiency (battery mode)	>94%	>94%	>94%
Battery	Rated voltage	24Vdc	24Vdc	48Vdc
	Constant voltage charging voltage (Optional)	28.2Vdc	28.2Vdc	56.4Vdc
	Floating charge voltage (Optional)	27Vdc	27Vdc	54Vdc
charger	PV charging method	MPPT	MPPT	MPPT
	PV max input power	1500W	3500W	5500W
	MPPT tracking range	30~115Vdc	120~430Vdc	120~430Vdc
	Max PV input voltage	145Vdc	450Vdc	450Vdc
	Max PV charging current	60A	60A	80A
	Max AC charging current	60A	60A	80A
	Max charging current	120A	60A	80A
Display	LCD display	Operating mode/load/input/output, etc.
Communication port	RS232	5PIN/Pitch2.0mm, baud rate 2400
	Expansion & configuration port	2×5PIN/Pitch2.54mm, lithium battery BMS communication card, WIFI card, dry contact card, etc.
	Parallel interface	No	Yes
Environmental parameters	Operating environment temperature	0~40℃
	Operating environment humidity	20%~95%（Non condensing）
	Storage temperature	-15~60℃
	Altitude	The altitude should not exceed 1000m, derating above 1000m, up to 4000m, refer to IEC62040
	Noise	≤50db
Certifications		EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1

solar inverter with battery

solar battery 150ah price

pv inverter

3 phase solar inverter

off grid solar inverter

Why Grid-Tied Inverter Is Best For Solar Panels?

Inverters have several exciting features that make them the best for solar panels. Using solar energy is vital in reducing global warming and the greenhouse effect. Grid-tied PV inverters have an added functionality besides converting the solar energy from AC to DC.

A grid-tied inverter converts the constantly varying DC solar power and feeds it into the grid. It synchronizes the frequency and the output voltage to its connected grid. When solar energy increases, the inverter output increases too, injecting into the grid. Since some electricity companies pay for the extra power, you can get monthly checks or municipal subsidies.

If solar energy is insufficient, a grid-tied PV inverter switches and starts drawing power from the grid into your home. It acts as a power backup in case solar energy is inadequate. It ensures there is a seamless power supply at your home. Grid-tied inverters are multi-functional and work energetically and powerfully.
