Name: China Full Spectrum Smd Led 5730 2835 5050 3030 Suppliers, Manufacturers, Factory - Best Price - Benwei
Brand: Benwei
SKU: 189761303

Shenzhen Benwei Lighting Technology Co., Ltd. is one of the best manufacturers and suppliers of full spectrum smd led 5730 2835 5050 3030 in China. Welcome to buy durable products for sale here and get pricelist from our factory. All customized products are with high quality and competitive price.

full spectrum smd led 5730 2835 5050 3030

led 5050 5630

Product Features of full spectrum smd led 5730 2835 5050 3030:

Slim size SMD package: design flexibility

Famous brand chip: San'an & Epistar chip

0.2w, 0.5w power available

High brightness 50-75LM

CRI80, CRI90M CRI96, CRI97+

R,G,B,Y,A UV,IR light color

Phosphor blue, green, amber...

Full spectrum 380-850nm

Stable reliability, low thermal resistance

Specifications:

5730 LED SERIES SPECIFICATION
Product Name	Light Color	CCT/Wavelength	Voltage	Current	Lumen	Remark
0.5W 5730 LED	Gold Yellow	1800-2000K	2.8-3.4V	150mA	55-60LM	CRI80,90
0.5W 5730 LED	White	3000-6500K	2.8-3.4V	150mA	55-75LM	CRI80,90,96+
5730 UV LED	UV	365-370nm	2.8-3.4V	150mA	/	0.5W
5730 UV LED	UV	375-420nm	2.8-3.4V	150mA	2-4LM	0.5W
5730 Blue LED	Blue	440-470nm	2.8-3.4V	150mA	10-14LM	0.5W
5730 Green LED	Green	520-530nm	2.8-3.4V	150mA	40-45LM	0.5W
2835 Yellow LED	Yellow	590-595nm	2.0-2.4V	150mA	14-16LM	0.5W
5730 Amber LED	Amber	600-610nm	2.0-2.4V	150mA	12-14LM	0.5W
5730 Red LED	Red	620-630nm	2.0-2.4V	150mA	20-24LM	0.5W
5730 Far Red	Far Red	660-665nm	2.0-2.4V	150mA	8-9LM	0.5W
5730 IR LED	IR	730-740nm	1.8-2.4V	150mA	/	0.5W
5730 PC Blue	Phosphor Blue	450-470nm	2.8-3.4V	150mA	20-30LM	0.5W Customized WD,WP
5730 PC Green	Phosphor Green	510-530nm	2.8-3.4V	150mA	50-70LM
5730 PC Color	Phosphor Amber/Red	600-630nm	2.8-3.4V	150mA	30-40LM

More pictures:

led lamp diode

a light emitting diode

led cob chip on board

led module 2835

led smd 2835 3v

led smd 2835 12v

rgb led 2835

smd 2835 5050

smd led 12v

FAQ:

Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 1-3 days, mass production time needs 3-7 days according order quantity .

Q3. Do you have any MOQ limit for led light order?What's the Payment way ?

A: MOQ is 100pcs for each model. We accept T/T Paypal and Western Union three ways payment.

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for led light?

A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

Q6. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 3 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
