Installation methods of explosion-proof lamps in different situations Wall-mounted equipment
One of the most important explosion-proof principles of explosion-proof lamps is that the temperature of the surface of the shell touched by dust, the surface of explosion-proof led lamp parts or the surface of electronic components is lower than the temperature of the electric touch surface. LED explosion-proof lights used outdoors require waterproof drivers. LED explosion-proof lights used in gas stations need to be shockproof! Through continuous improvement, explosion-proof lamps are now suitable for many industries, and the effect can be used with confidence.
Installation methods of explosion-proof lamps in different situations Wall-mounted equipment: first install the lamp body on the wall or other support through the bracket (make sure the shading plate is directly above the bulb), and then pass the cable through the joint, gasket, seal in turn Circle until it is inside the junction box (reserve a certain length of cable for easy wiring), and finally tighten the connector and tighten the set screw. Vertical boom type equipment: first pass the connector through the cable, screw it into the steel pipe, tighten the set screw, and then pass the cable through the gasket and the sealing ring in sequence until it is inside the junction box (reserve a certain length of cable to facilitate wiring), Then tighten the lamp body and the connector, and tighten the set screw. Ceiling-mounted equipment: screw the 3/4-inch adapter into the ceiling-mounted adapter, screw the connector into the 3/4-inch adapter, tighten the set screws separately, and then pass the cables, the equipment is on the roof, and finally pass the cables in sequence. Pass the gasket and sealing ring to the junction box (reserve a certain length of cable to facilitate wiring), then tighten the lamp body and the connector, and tighten the set screw.
When the lamp is tilted, adjust the relative orientation of the joint and the steel pipe to ensure that the shading plate is directly above the bulb; when installing and protecting the lamp, first cut off the power supply; when in use, the surface of the lamp will have a certain temperature rise, which is a normal phenomenon, and the temperature of the transparent core high and must not be touched. Explosion-proof lamps should be checked from the nameplate and product specification before installation: explosion-proof type, category, level, group; protection level of the shell; installation method and fastener requirements for installation, etc.
The single-plug starterless fluorescent lamp is a cold-cath gas discharge lamp. The light-emitting principle is to use the electric discharge to make the mercury atoms generate ultraviolet radiation, and then excite the fluorescent material on the inner wall of the lamp to emit light. This kind of fluorescent lamp has higher luminous power (about 3 times that of incandescent lamp), longer service life, and does not require a starter when starting (generally, there is a conductive layer on the wall of the lamp tube, called the ignition layer, and the starting point of the fluorescent lamp is The glow depends on it to end; when the lamp tube breaks, the glow layer is also damaged, and the lamp is extinguished), the negative temperature is low (about 200 ℃), it is a safe and effective light source, and it is very suitable for making safety-enhancing lighting. lamps.
